. Thank you for purchasing the RADAR 1500 MK@ LCD radar. Thisproduct will provide many years of trouble free use when operatedproperly, so it is important that you read and observe the precautions below.● Read this manual thoroughly to gain a good understanding of the capabilities and the requirements of this equipment.● Store the manual in a safe location so, that it does not become lost or damaged.● Observe standard storage and handling procedures for electronic equipment. Operating PrecautionsWARNINGTo avoid electrical shock, never touch the inside of the scanner whenit is connected to an electrical supply.Always keep the protective cover on the scanner when it is connectedto an electrical supply. High internal voltages can cause serious personal injury.

• Jrc 1500 Radar

The equipment should be routinely serviced, only by JRCauthorised personnel.Avoid passing close to the scanner when the radar is in use.The scanner unit rotates quickly and can cause personal injury. Equipment PhotographsSCANNER UNIT NKE-1063DISPLAY UNIT NCD-3970AIII. Table of ContentsSymbols Used In This Manual - IOperating Precautions - IIEquipment Photographs - IIIGlossary of radar terms - IVSECTION 1 EQUIPMENT OVERVIEW - 11.1 FUNCTION - 11.

4.114.124.134.144.154.164.174.184.194.204.214.224.234.244. Glossary of radar termsThe following is a list of abbreviations and acronyms which may be used in thetext of the manual.A/DALMAnalog to Digital conversionAlarm In, also known as the approach alarm.

Jrc 1500 Radar

Used to warn of approach to a preset zone or to a zoned target. SECTION 1EQUIPMENT OVERVIEW1.1 FUNCTIONCongratulations on selecting the JRC RADAR 1500 MK2 LCD system toassist with your navigation.Whether you purchased this radar because of its compactness, power economy,ease of installation, or long term reliability, one thing is certain, the momentyou turn on your RADAR 1500 MK2 Display you will know that you areseeing a revolutionary new concept in radar technology. You are the proud ownerof a radar system unmatched in the marine recreational industry.

1.3 COMPONENTSThe table below lists the components which are included with your new radarsystem.DescriptionModel No. 1.4 DIMENSIONSFIG.

1-1 DISPLAY MOUNTING DIMENSIONSFIG. SECTION 2NAMES AND FUNCTIONS OF THECOMPONENTSDISPLAY UNITVRM/EBL KeyJ-DialJoystick with MENU/ENTOFFSET KeyContrast/Dimmer KeyTransmit/off KeyStand-by/off KeyDISPLAY UNITLATCHINTER UNITCONNECTORPOWER INPUT/NMEA/COMPASSCONNECTORFIG. 2.1 CONTROL PANEL① STAND-BY/OFF Key・ Turns ON power to Display and Scanner and activates 90 second countdown timer.・ Press STBY/OFF key to go into Stand-by mode while in the Transmit mode.・ Press STBY/OFF and X-MIT/OFF keys simultaneously to turn radar off.② TRANSMIT/OFF Key・ Turns transmitter ON and activates Radome.・ Press STBY/OFF and X-MIT/OFF keys simultaneously to switch off theradar.③ J-DIAL・ Push repeatedly to select RANGE, SEA, RAIN, GAIN, TUNE controls. TRAILEXPIRDISPLAYTX-PLANTX PERIODSTBY PERIODTUNE⑥・⑦・・6OFFOFFOFFDAYSHORTONONNIGHTLONGALL 10 20 30 SCANS3 5 10 15 MINSAUTO MANUALINITIAL SET UP MENURELATIVE BEARING ALIGNMENTDISPLAY TIMINGTUNE PRESETSTC PRESETBUZZER VOLUME ON OR OFFOPER. PROMPTSLANGUAGEOFFSET KeyTo shift own ship on screen.CONTRAST/DIMMER KeySetts LCD contrast.Sets back light for LCD and panel illumination. SECTION 3INSTALLATIONThis section provides practical guidelines to assist in the planning and installation of the RADAR 1500 MK2.3.1 UNPACKING AND INSPECTIONUse care when unpacking the RADAR 1500 MK2 from the shipping carton toprevent damage to the contents.

It is also good practice to save the carton andthe interior packing material until the radar has been satisfactorily installed.The original packing material should be used in the unlikely event that it isnecessary to return the unit for service. 3.3 MOUNTING THE DISPLAY UNITWhen planning the installation for your display unit, the following conditionsshould be considered to ensure dependable and trouble-free operation.1) The mounting location should be accessible enough to allow easy operationof all the front panel controls.2) There should be adequate ventilation.3) There should be sufficient space behind the display unit to allow for cableconnections to its rear.4) The display unit should be located near a DC power source.

When the display unit is mounted overhead, remove the mounting plate, whichis secured by four screws and rotate it through 180 degrees for re-assembly onthe other side of the unit.4 SCREWSBRACKETDISPLAY UNITMOUNTINGPLATEBRACKETThe display unit is separated fromthe bracket in the shipping carton.Install the display unit by slidingit onto the bracket until it is fullyseated.To remove the unit simply depress the latch on the rear of thedisplay unit and lift. 3-3 DISPLAY MOUNTING DIMENSIONSFIG. 3.4 MOUNTING THE SCANNER UNITCAUTIONThe scanner unit requires a minimum mounting surface thickness of 3 mm (0.12 inches).

If the thickness of the mounting baseis less than this, additional flat washers are required. If the thickness is more than 15 mm (0.6 inches), longer hexhead bolts arerequired.Selecting an adequate location for the scanner unit requires careful consideration.

Usually, the mounting surface for thescanner unit should be parallel withthe ship’s waterline. Some vessels,however, may adopt a higher bowangle at some cruising speeds. Thissubstantially alters and raises theradar’s radiation plane. In this casenearby target detection might bepoor.

It may be helpful to lower theradar beam towards the FORWARDparallel by shimming the radar pedestal in order to tilt the beam angleslightly downward with respect tothe waterline. 3-6 ASSEMBLING PROCEDURE FOR CABLE14INSTALLATIONbSHIELD COVERaCABLEaREDOMETURN THE RADIATORTHIS DIRECTION.bcGASKET BGASKET AdcedeGASKET BGASKET ADON'T PILE GROOVES. 3.6 ELECTRICAL CONNECTION3.6.1 DC POWER CABLEThe RADAR 1500 MK2 will work with any electrical supply within the 10.2to 16 V range, since it contains a power regulator circuit.

Connect the powercable to a DC source capable of supplying at least 3.5 A. The power cableshould normally be wired through a circuit breaker. The red lead wire of thepower cable must be connected to the positive source terminal and the blacklead to the source negative terminal.

3-7 INTERCONNECTION DIAGRAM16INSTALLATION1A2APWVDVDRTIR/GSRTI/GSBZ/TUNITUNV+12VSHIP'S MAINTS (+)SHIP'S MAINTS (–)NAV-AID (+)NAV-AID (–)COMPASS (+)COMPASS (–)EP1P2WHTYELT.ORNT.REDT.BLUGRNCOAXSHLDSHLDT.REDT.BLKYELGRNBLUWHIDISPLAY UNIT NCD-3970TO NAV-AID'S+:Data Output–:Data GroundTO COMPASS'S+:Data Output–:Data GroundTO SHIP'S POWERCFQ-8571-10(10m)CFQ-8768-15(15m)CFQ-8768-20(20m)CFQ-8572 (2m)SHLDCOAXSHLDWHIGRNYELT.REDT.BLUT. DISPLAY UNITTO SCANNER UNITYEL(+)TO NAV-AIDGRN(–)+: NAV-AID'S Data OutputBLU–: NAV-AID'S Data Ground(+)TO COMPASS(–)+: COMPASS'S Data OutputWHI–: COMPASS'S Data GroundREDFUSEBLK+–2V1DCBATTERYFIG. 3.7 INITIAL OPERATION AND SET UP3.7.1 INSPECTION AFTER INSTALLATIONAfter completing the installation and prior to energizing the equipment, it isnecessary to ensure that all steps of the installation were accomplished in accordance with the instructions. Make sure that:(1) The cables are not pinched or damaged.(2) The allowed voltage is not exceeded and the polarity is correct.(3) All bolts are tight.(4) The power cable shields has been properly connected to Boat Main ground.3.7. 3.7.3 TUNE PRESETPerform this step after the radar has been X-MITTING for 10 minutes.① Set the range to 3 NM.② Set gain to desired level.③ Turn SEA and RAIN all the way down.④ Turn IR off.⑤ In the INITIAL SET UP MENU select Tune preset.⑥ Move the bar to using the J-DIAL to get the strongest signal back.Note: There may be 2 positions where the targets are strong. Pick the strongest of the 2.⑦ Press the JOYSTICK to save and exit. 3.7.5 RELATIVE BEARING ALIGNMENTThis step must be performed.

Failure to do so may result in incorrect bearingreadings.① Set the range to 1.5 NM.② Identify a suitable target such as a buoy and position the boat between 0.5NM and 1 NM.③ Point the bow at the target.④ In the INITIAL SET UP MENU select BEARING.⑤ Locate the target on the display.⑥ Move the marker over the target.⑦ Press the JOYSTICK once.⑧ Move cursor back to the SHM (Ships Heading Marker is the solid verticalline on the display). 3.7.7 Buzzer ON or OFF① In the INITIAL SET UP MENU select BUZZER.② Select ON or OFF.③ Press JOYSTICK when done.3.7.8 OPERATOR PROMPTSOperation prompts can be helpful to new users operating the radar. The defaultsetting is ON.① In the INITIAL SET UP MENU select OPER.PROMPT.② Select ON or OFF.③ Press JOYSTICK when done.3.7.9 LANGUAGEEnglish is the default language. It can be changed to Spanish, French, German,Norwegian, and Italian.① In the INITIAL SET UP MENU select LANGUAGE. SECTION 4OPERATIONIn normal operation the RADAR 1500 MK2 is very easy to use and several ofits functions are totally automatic. However, the prudent navigator spends timein good visibility to learn the layout of the controls and to become proficient intheir use, so that he/she will obtain the best performance from the equipmentwhen the visibility is poor, or the sea area is crowded.This section takes you through the controls step-by-step.4.

4.2 TURNING THE RADAR ON AND OFFTO TURN ONTO TRANSMITTO STAND-BYTO TURN OFFPress the STBY/OFF key.Press the X-MIT key.Press the STBY/OFF key.Press the STBY/OFF key and the X-MIT/OFF key simultaneously.When youPress the STBY/OFF key, a 90 second warm-up count down timer is activatedand displayed together with the total (display unit) usage to date.Press the X-MIT/OFF key, the radar transmits, the scanner begins to rotate andechoes will appear on the screen. INTERFERENCE REJECTION 'ON'TARGET EXPANDER 'ON'RANGE RING INTERVAL (NM)RANGE SCALE (NM)OWN SHIP COURSE DATAOWN SHIP SPEED DATASELECTING J-DIALLEVEL INDICATORTUNE INDICATORNAVIGATION DATATRAIL 'ON'POSITION DATAGUARD ZONE ALARM 'ON'FIG. 4.3 SELECTING A RANGEPress the J-DIAL until RANGE is highlighted in the upper right corner of thedisplay.

The range scale and range rings setting in use is shown in the upper leftcorner. Rotate the J-DIAL clockwise to increase the range and anti-clockwiseto decrease it. The range rings are automatically set to correspond with thisselection.4.4 ADJUSTING RECEIVER SENSITIVITYPress the J-DIAL until GAIN appears highlighted in the upper right corner ofthe display.

4.6 REDUCING SEA CLUTTERCAUTIONIncreasing the SEA CLUTTER control effectively diminishes theradar’s sensitivity. SEA CLUTTER should never be advanced tothe point where it obliterates all returns from waves, since thissetting could prevent the detection of nearby targets, especiallysmall wood/grp boats and yachts approaching head-on. 4.10 SETTING 1/4 OFFSETBy pressing the OFFSET key, the display is offset downwards by 1/4 radius,expanding the display area in front of the vessel. Bible study guide questions. Press the key a second time toreturn the display to normal.OFFSET MODE OFFOFFSET MODE ON4.11 RANGE MEASUREMENT(1) Count the number of range scale rings in use between the center of thescreen and the ring preceding the target. Add to this distance an estimate ofthe distance between this nearest ring and the inner edge of the target. (3) Using cursorPress the JOYSTICK to make the cross cursor appear on the screen.

Thecross mark can be moved any direction by using the JOYSTICK. The rangeand bearing will be displayed at the lower right corner on the display.4.12 BEARING MEASUREMENT(1) Using the bearing scaleUsing the bearing scale on the screen, visually estimate a line from the center of the display (ship’s position) projected through the center of the target,to reach the bearing scale around the perimeter of the display. 4.13 OPERATING MENUPress the JOYSTICK to access the first menu sheet.The JOYSTICK is then used to select a particular menu. Press again to open upthe sub menu, which will be displayed to the right side of the selected menu” mark.

The DISPLAY can be scrolled for the second menuwith the “sheet which is below IR selection. GUARD on the first menu sheet is belowTUNE on the second menu and so on.Pressing the JOYSTICK again will return the display to the normal video presentation.FIRST MENUFIG. 4.14 SETTING GUARDThe guard zone alarm is effective for alerting the operator to targets approaching his own ship. An alarm is sounded when any (apparent) target returning anecho above the noise threshold is detected. If sea clutter, or other incidentalechoes trip the alarm, adjust the gain control and/or the sea clutter to avoid thisfalse alarming.① Press the JOYSTICK to display the menu sheet.② Select GUARD-ON and press the JOYSTICK.

The radar display returns tothe normal video presentation. 4.15 RINGSThe range rings can be turned to on or off via this menu.4.16 POSITIONSelect this option to display the ship’s position (derived from a navaid input).This function allows selection of ship’s position in latitude/longitude (LL), timedifference (TD) position, you may also display waypoint (WPT) as a LL position in place of your own position data. This menu also removes this data fromdisplay. 4.20 TARGET EXPANSIONTarget expand mode can be set to “on” or “off”. When “on”, this function increases the size of the displayed images to make small targets appear larger andeasier to view on screen.

When active,“EXP” is highlighted in the upper leftarea of the screen.4.21 INTERFERENCE REJECTIONCAUTIONIf you’ll watch the RADAR BEACON and the SART, set the process as follows.IR OFFInterference Rejection (IR) mode can be set to “on” or “off”. 4.24 SETTING AUTO/MANUAL TUNINGThe Radar 1500 MK2 can be tuned either automatically or manually. IfMANUAL TUNING is selected, a tuning bar indicator is displayed. AUTOTUNE mode will automatically tune the radar for optimum reception wheneverthe radar is turned on, even if ranges are changed.4.25 In Case an Unusual Condition Occurs during OperationIf the operator encounters unusual conditions, such as:-・The screen is disturbed.・The machine accepts no key input. 4.26 DISPLAY OF RADAR TRANSPONDERSART (Search and Rescur Radar Transponder) is life preserving device approved by GMDSS which is used for locating survivors in the event of a disaster or distress. SART operates in the 9 GHz frequency band.

When it receives aradar signal (interrogating radio wave) of 9 GHz transmitted by a rescue ship oraircraft radar, SART transmits a series of respouse signals to the searchers toindicate the distress position. SECTION 5MAINTENANCEThe purpose of this section is to provide instructions for the service technician.The RADAR 1500 MK2 is designed to provide long periods of trouble freeoperation. However, environmental and other factors may require this equipment to be periodically serviced.WARNINGThis radar equipment contains high voltage. Adjustments require specialized service procedures and tools only available toqualified service technicians. (2) Check for any evidence of corrosion in the scanner unit and display unit,or their cables and connecotrs. Clean as reuired.(3) Check that the cable connector is secure.5.2 CLEANING (MONTHLY INTERVALS)Wash the exterior of the scanner with fresh water, but do not immerse the unit.A heavy deposit of dirt, or caked salt on the surface.

T o avoid electrical shock, never touch the inside of the scanner when it is connected to an electrical supply. Always keep the protective cove r on the scanner when it is connected to an electrical supply. High internal voltages can cause serious per- sonal injury. The equipment should be routinely serviced, only by JRC authorised personnel. A void passing close to the scanner when the radar is in use.

The scanner unit rotates quickly and can cause personal injury. Both this and the enclosed radome should be installed at a high place, such as a cabin roof, or a specially constructed arch, or radar mast. If the radiating units cannot be installed above all possible, standing head height, they should be guarded by a strong, protectiv e, enclosing frame.

Prolonged, close range exposure to radar signals is not recommended. Before approaching close to the scanner, or dismounting it, ensure that the STBY/OFF and the X-MIT/OFF keys on the display unit have both been turned off. The cable connector P1 at the rear of the display unit should be disconnected before removing the scanner unit from its installed position. Never sit on the scanner, nor otherwise subject them to weight.

They are not intended to bear loads and ignoring this advice could cause damage to important internal components. You will only get optimum performance from your RADAR 1000 MK.
